[RE-wrenches] Low voltage DC v. higher voltage DC

Drake drake.chamberlin at redwoodalliance.org
Fri Sep 21 08:52:30 EDT 2018

That being said, SMA is loosing a lot of sales by
not having a split phase Sunny Island on the
market. It would be my unit of choice for many
application that I have gone with other brands.
The price of a pair of SIs is often just not competitive.

  At 12:25 AM 9/21/2018, you wrote:
>Content-Language: en-US
>Content-Type: multipart/related;
>
>boundary="_010_DB7PR04MB4506FEAEB9C7C3E0387F51EFBB120DB7PR04MB4506eurp_";
>         type="multipart/alternative"
>
>Tump - You are right about the large number of
>times that has been asked, and I wish I had a happy answer.
>
>However, with all the work on Sunny Boy Storage
>and Sunny Central Storage (and even a Tripower
>storage), resources to develop and test a split
>phase Sunny Island are not available.  There is
>active work on updating the communications to
>support SMA’s Ethernet based communications.  Still, this may be months out.
>
>With the Smartformer being discontinued, the
>MidNite MNX-240 is the recommended part to
>create 240 split phase from one Sunny Island.
>
>Best regards –
>Mike
>
>
>SMA America
>Michael Mahon
>Technical Trainer, Solar Academy
>6020 West Oaks Boulevard, Suite 300
>Rocklin, CA 95765
>U.S.A.
>Mobile:   +1 916 918 9412
><http://www.sma-america.com/>www.SMA-America.com
>
>Solar Academy:
><http://www.sma-america.com/partners/sma-solar-academy/overview.html>www.SMA-America.com/partners/sma-solar-academy/overview.html
>
>Full training schedule:
><https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html>https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html
>
>
><http://www.facebook.com/pages/SMA-America/140290312717395>
>http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/fa
>  <http://twitter.com/SMA_America>
>http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/tw
> <http://www.smainverted.com/>
>http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/wo
> <http://www.linkedin.com/company/364675>
>Linkedin Logo
> <http://www.youtube.com/playlist?list=PL840A5336CAC32332>
>http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/yo
> <http://smaadvance.com/signup/>
>SMAAFORUM_ICON
>
>cid:image008.jpg at 01D43B9E.70803930
>
>
>
>This email and any attachments thereto may
>contain SMA America, LLC confidential,
>privileged and private material for the sole use
>of the intended recipient. Any review, copying,
>or distribution of this email (or any
>attachments thereto) by others is strictly
>prohibited. If you are not the intended
>recipient, please contact the sender immediately
>and permanently delete the original and any
>copies of this email and any attachments thereto. Thank you.
>
>From: RE-wrenches
><re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Tump
>Sent: Thursday, September 20, 2018 4:01 PM
>To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
>Subject: Re: [RE-wrenches] Low voltage DC v. higher voltage DC
>
>I bet Mike could retire from the industry if he
>had a nickel for every time he was asked
>for/about that. I’ve asked Santa for years

 €¦ still waiting. T
>On Sep 20, 2018, at 5:21 PM, Chris Schaefer
><<mailto:chris at solarandwindfx.com>chris at solarandwindfx.com> wrote:
>
>Hey Michael from SMA, any chance we can finally
>get an 240vac SI here in the states?
>
>Christopher
>
>On Tue, Sep 18, 2018 at 12:11 PM, Harry Mahon
><<mailto:Michael.Mahon at sma-america.com>Michael.Mahon at sma-america.com> wrote:
>Marco – <
>
>I will need to ask for information about the BYD
>availability.  Once those units have all
>required listings/certifications and are
>available in US, they should be ready to use
>with SBS.  The CANBUS comms to the BMS has
>already been vetted, and they are on the SMA
>Approved battery list already.  But I will get
>confirmation on the immediate usability.
>
>Best regards –
><Mike
>
>
>
>
>SMA America
>Michael Mahon
>Technical Trainer, Solar Academy
>6020 West Oaks Boulevard, Suite 300
>Rocklin, CA 95765
>U.S.A.
>Mobile:   +1 916 918 9412
><http://www.sma-america.com/>www.SMA-America.com
>
>Solar Academy:
><http://www.sma-america.com/partners/sma-solar-academy/overview.html>www.SMA-America.com/partners/sma-solar-academy/overview.html
>
>Full training schedule:
><https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html>https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html
>
>
><http://www.facebook.com/pages/SMA-America/140290312717395><image001.jpg>
><http://twitter.com/SMA_America><image002.jpg>
><http://www.smainverted.com/><image003.jpg>
><http://www.linkedin.com/company/364675><image004.jpg>
><http://www.youtube.com/playlist?list=PL840A5336CAC32332><image005.jpg>
><http://smaadvance.com/signup/><image006.png>
><image007.jpg>
>
>
>This email and any attachments thereto may
>contain SMA America, LLC confidential,
>privileged and private material for the sole use
>of the intended recipient. Any review, copying,
>or distribution of this email (or any
>attachments thereto) by others is strictly
>prohibited. If you are not the intended
>recipient, please contact the sender immediately
>and permanently delete the original and any
>copies of this email and any attachments thereto. Thank you.
>
>From: RE-wrenches
><<mailto:re-wrenches-bounces at lists.re-wrenches.org>re-wrenches-bounces at lists.re-wrenches.org>
>On Behalf Of Marco Mangelsdorf
>Sent: Monday, September 17, 2018 10:20 PM
>
>To: RE-wrenches
><<mailto:re-wrenches at lists.re-wrenches.org>re-wrenches at lists.re-wrenches.org>
>Subject: Re: [RE-wrenches] Low voltage DC v. higher voltage DC
>
>
>Mahalo Mike.
>
>Can you tell us please when the SS will actually
>be able to integrate the BYD battery platform in the north American market?
>
>marco
>
>On Monday, September 17, 2018, Harry Mahon
><<mailto:Michael.Mahon at sma-america.com>Michael.Mahon at sma-america.com> wrote:
>Marco and all – yes that is the correct spec
>ssheet for the BYD batteries that will work with Sunny Boy Storage.
>
>SMA strongly would recommend the Sunny Island
>for off-grid in general and certainly whole home
>backup.  See the attached from Home Power
>April/May 2011; quad stack of SIs acting as UPS
>for the home – just charging batteries when grid
>is prresent, powering home with batteries/PV
>when grid is gone.  A dual split phase cluster
>is almost 24,000 W continuous (!) capability and
>can handle crazy power factor loads with no
>issues.  Built in generator functions and two
>relay positions per Sunny Island allow for lots
>of redundancy and fail-safe load shedding to be built in.
>
>The Sunny Boy Storage (SBS) is designed to be a
>grid-tied inverter to allow higher self
>consumption of local PV power.  Even with the
>ABU to allow off grid operation (grid forming on
>its AC outputs rather than just on the dedicated
>120VAC Secure Power Supply outlet), there can be
>a several second delay in the switch from grid
>power to microgrid as the ABU must signal the
>Sunny Boy Storage that it has disconnected from
>the grid and that it is safe for the SBS to form
>a grid on its output terminals.  Also be aware
>that there is no master-slave configuration
>ability with the SBS – they will always assume
>they are acting independently on their energy meter input information.
>
>Best regards –
>Mike
>
>SMA America
>Michael Mahon
>Technical Trainer, Solar Academy
>6020 West Oaks Boulevard, Suite 300
>Rocklin, CA 95765
>U.S.A.
>Mobile:   +1 916 918 9412
><http://www.sma-america.com/>www.SMA-America.com
>
>Solar Academy:
><http://www.sma-america.com/partners/sma-solar-academy/overview.html>www.SMA-America.com/partners/sma-solar-academy/overview.html
>
>Full training schedule:
><https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html>https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html
>
>
><http://www.facebook.com/pages/SMA-America/140290312717395><image001.jpg><http://twitter.com/SMA_America><image002.jpg>
><http://www.smainverted.com/><image003.jpg>
><http://www.linkedin.com/company/364675><image004.jpg>
><http://www.youtube.com/playlist?list=PL840A5336CAC32332><image005.jpg>
><http://smaadvance.com/signup/><image006.png>
><image007.jpg>
>
>
>This email and any attachments thereto may
>contain SMA America, LLC confidential,
>privileged and private material for the sole use
>of the intended recipient. Any review, copying,
>or distribution of this email (or any
>attachments thereto) by others is strictly
>prohibited. If you are not the intended
>recipient, please contact the sender immediately
>and permanently delete the original and any
>copies of this email and any attachments thereto. Thank you.
>
>From: RE-wrenches
><<mailto:re-wrenches-bounces at lists.re-wrenches.org>re-wrenches-bounces at lists.re-wrenches.org>
>On Behalf Of Marco Mangelsdorf
>Sent: Saturday, September 15, 2018 10:08 PM
>To: 'RE-wrenches'
><<mailto:re-wrenches at lists.re-wrenches.org>re-wrenches at lists.re-wrenches.org>
>Subject: Re: [RE-wrenches] Low voltage DC v. higher voltage DC
>
>Sabaidee from Vientiane, Lao PDR.
>
>Attached is the spec sheet on the BYD battery in question.
>
>I’ve confirmed with SMA directly that
>there’s no capability for the Sunny Storage
>design (S.S., ABU and battery) to use a
>generator input.  My apologies for mis-stating
>earlier that it could accommodate a generator.
>
>As far as grid-tie with batteries, the Holy
>Grail as far as I’m concerned is being able to
>provide whole house back-up and not have to do
>the old fashioned and pain in the arse critical
>load sub-panel.  The more choices that we’re
>provided, the more better.  So I’m pleased
>that companies like SMA, Ensync, SolarEdge and
>others are bringing new equipment and designs to
>market to allow for whole house back-up.
>
>marco
>
>From: RE-wrenches
>[<mailto:re-wrenches-bounces at lists.re-wrenches.org>mailto:re-wrenches-bounces at lists.re-wrenches.org]
>On Behalf Of jay
>Sent: Saturday, September 15, 2018 5:00 AM
>To: RE-wrenches
>Subject: Re: [RE-wrenches] Low voltage DC v. higher voltage DC
>
>HI Harry,
>
>The battery is charged from the AC side correct?
>And is the charging algorithm inside the ABU.
>
>If so why couldn’t you use a generator to charge the battery?
>
>jay
>
>peltz power
>
>
>
>On Sep 13, 2018, at 7:10 AM, Harry Mahon
><<mailto:Michael.Mahon at sma-america.com>Michael.Mahon at sma-america.com> wrote:
>
>Marco –
>
>The Sunny Boy Storage “Advanced Backup Unit”
>accessory or ABU will be discussed at SPI in a
>couple weeks – first units are being stockeed
>now at our warehouses in US.  The ABU will allow
>the SBS to be a grid former in case of utility
>outage, however there are no plans to have any
>generator inputs/controls to allow for battery charging from generat
>And yes, BYD BBox HV 5.12/7.68/10.24 devices
>will be supported when available in US (will be this year I understand)
>
>Mike
>
>-----
>
>
>The SMA Sunny Storage looks promising.
>
>It will be able to work with the LGC RESU10 HV battery and, sooner rather
>than later I hope, BYD package as well.
>
>And it will allow for a backup generator tie in.
>
>Ta-dah!
>
>marco
>
>On Thursday, September 13, 2018, Bruce Erickson
><<http://lists.re-wrenches.org/listinfo.cgi/re-wrenches-re-wrenches.org>bruce
>at mendocinosolar.com>
>wrote:
>
> > Hi Marco,
> >
> > I partially agree with you. I recently bid Outback, StorEdge, and Pika
> > options for a GTBB customer, partly to understand pricing for myself, and
> > found OB to be so much more expensive. The customer really wanted a system
> > that would be to be able to charge the batteries off a generator in an
> > outage, understandably. But the extra thousands in cost for OB ended up
> > being prohibitive. Add-on rapid shutdown is a
> killer. So he’s opting for a
> > nice modern high voltage DC system, with optimizers and built-in RSD, but
> > when there’s an extended outage, he’ll
> have to hope the sun comes out right
> > after the storm to recharge the batteries, or he’ll end up in the dark
> > again, until the grid comes back. Maybe there’s a high voltage inverter
> > that allows generator charging, or a
> third-party battery charger, that I’m
> > not aware of. Otherwise high voltage systems are very limited for backup,
> > at least in winter storm scenarios.
> >
> > *Bruce Erickson*
> > Mendocino Solar Service
> > PO Box 1252
> > Mendocino, CA 95460
> > 707-937-1701
> > 707-937-1741 fax
> >
> <http://lists.re-wrenches.org/listinfo.cgi/re-wrenches-re-wrenches.org>bruce
> at mendocinosolar.com
> >
> > *Connecting Mendocino County to Solar Since* *1994*
> >
> >
>
>_______________________________________________
>List sponsored by Redwood Alliance
>
>List Address:
><mailto:RE-wrenches at lists.re-wrenches.org>RE-wrenches at lists.re-wrenches.org
>
>Change listserver email address & settings:
><http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org>http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org
>
>List-Archive:
><http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html>http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html
>
>List rules & etiquette:
><http://www.re-wrenches.org/etiquette.htm>www.re-wrenches.org/etiquette.htm
>
>Check out or update participant bios:
><http://www.members.re-wrenches.org/>www.members.re-wrenches.org
>
>
>
>_______________________________________________
>List sponsored by Redwood Alliance
>
>List Address:
><mailto:RE-wrenches at lists.re-wrenches.org>RE-wrenches at lists.re-wrenches.org
>
>Change listserver email address & settings:
><http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org>http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org
>
>List-Archive:
><http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html>http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html
>
>List rules & etiquette:
><http://www.re-wrenches.org/etiquette.htm>www.re-wrenches.org/etiquette.htm
>
>Check out or update participant bios:
><http://www.members.re-wrenches.org/>www.members.re-wrenches.org
>
>
>
>
>--
>Chris Schaefer’s
><http://www.solarandwindfx.com/>
>[]
>
>Tel/Fax 585-229-2083 or Cell 585-748-1870
>5115 South Hill Road ~ Canandaigua New York 14424
><http://www.solarandwindfx.com/>www.solarandwindfx.com
>~ E-mail: <mailto:chris at solarandwindfx.com>chris at solarandwindfx.com
>[]
>
>Thomas Jefferson, the author of our great
>Constitution, once said, "democracy" will cease
>to exist when you take away from those who are
>willing to work and give to those who would not."
>_______________________________________________
>List sponsored by Redwood Alliance
>
>List Address:
><mailto:RE-wrenches at lists.re-wrenches.org>RE-wrenches at lists.re-wrenches.org
>
>Change listserver email address & settings:
><http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org>http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org
>
>List-Archive:
><http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html>http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html
>
>List rules & etiquette:
><http://www.re-wrenches.org/etiquette.htm>www.re-wrenches.org/etiquette.htm
>
>Check out or update participant bios:
><http://www.members.re-wrenches.org>www.members.re-wrenches.org
>
>
><blocked::mailto:Tump at swnl.net%22%20%5Co%20%22blocked::mailto:Tump at swnl.net>Tump at swnl.net
><blocked::http://www.swnl.net/%22%20%5Co%20%22blocked::http://www.swnl.net/>www.SWNL.net
>                 Solarwinds Northernlights
>        Serving Mid Coast Maine & Northern California
>                          207-832-7574   Cl.
> 610-517-8401
>                               Blair "TUMP" May
>                ********  MAINE'S CHARTER ********
>                       NABCEP    "Certified PV Installer"
>
>               ********  MAINE'S CHARTER ********
>                   Trace Xantrex "Certified" Dealer / Installer"
>
>
>
>
>
>
>_______________________________________________
>List sponsored by Redwood Alliance
>
>List Address: RE-wrenches at lists.re-wrenches.org
>
>Change listserver email address & settings:
>http://lists.re-wrenches.org/options.cgi/re-wrenches-re-wrenches.org
>
>List-Archive:
>http://www.mail-archive.com/re-wrenches@lists.re-wrenches.org/maillist.html
>
>List rules & etiquette:
>www.re-wrenches.org/etiquette.htm
>
>Check out or update participant bios:
>www.members.re-wrenches.org
-------------- next part --------------
An HTML attachment was scrubbed...
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment.htm>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d7396.jpg
Type: image/jpeg
Size: 428 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73b5.jpg
Type: image/jpeg
Size: 428 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment-0001.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73c5.jpg
Type: image/jpeg
Size: 717 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment-0002.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73d4.jpg
Type: image/jpeg
Size: 731 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment-0003.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73e4.jpg
Type: image/jpeg
Size: 480 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment-0004.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73e4.png
Type: image/png
Size: 808 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment.png>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 2d0d73f3.jpg
Type: image/jpeg
Size: 18895 bytes
Desc: not available
URL: <http://lists.re-wrenches.org/pipermail/re-wrenches_lists.re-wrenches.org/attachments/20180921/ff20e2cc/attachment-0005.jpg>

More information about the RE-Wrenches mailing list
