[RE-wrenches] Sol-Ark 15KW is rock steady, but crazy wild grid voltages when connected to grid

[Kirpal Khalsa]

Scot,
We have had numerous SolArk 15k's with loose neutrals direct from the
factory.   Double check all the factory connections in the accessible
wiring compartment.  I brought it to their attention each time I found it.
They said they would do better on quality control bit obviously never heard
back after that.
Keep us posted what you find.
Thanks

Kirpal Khalsa
Oregon Solarworks


On Thu, Sep 12, 2024, 6:41 PM Blake Gleason via RE-wrenches <
re-wrenches at lists.re-wrenches.org> wrote:

>
> Definitely sounds like a loose neutral on the utility side (likely at the
> pole/tap).
>
> I suspect if you turn off and disconnect the Sol-Ark the light flickering,
> etc will continue (until the utility recrimps their neutral...)
>
> Blake
>
> On Thu, Sep 12, 2024 at 5:38 PM Scot Arey via RE-wrenches <
> re-wrenches at lists.re-wrenches.org> wrote:
>
>> I have Sol-Ark 15KW with 31kwh battery has been installed for year+.
>>
>>
>>
>> Customer has for two days been having grid voltage issue seen as dimming
>> lights. No neighbors reporting issues. He called his electrician who noted
>> one high conductor and the other low. Have seen this before unrelated to
>> solar and it was a bad neutral. His electrician says ok.
>>
>> Customer disconnects from the grid because the fluctuations so severe and
>> when he does, voltage issues go away and Sol-Ark is rock steady at
>> 120-volts per leg. I send my senior tech over to ensure we don’t have a
>> loose neutral or any grid conductors to the grid input. Nothing found.
>>
>> Picture attached of grid voltages from the Sol-Ark monitoring (very
>> helpful, I might add.)
>>
>> The electric cooperative is sending a tech out tomorrow. Any body have
>> insight or history with this?
>>
>>
>>
>>
>>
>>
