Dana,

        Specifically, I was looking for the power consumption of a propane-fired hot tub...interesting story about heating the water with the motor's waste heat though.

        Yes, I have several watthour meters also but the idea of going into a store and (I'm sure asking first) measuring watts of various appliances is great.  Why didn't I think of that?!

        Maybe the best test would be going into some of my neighbors' houses and conducting the same test after all the other 'related' equipment is added the a system, EG satellite dish, dvd, computer for streaming, etc. and get some real world totals  with the phantom load that goes with it (and to share with my customer to convince him/her to use a switched plugstrip).

        Thanks for all the other info for other loads, very helpful.

Bill


  ----- Original Message -----
  From: Dana
  To: 'RE-wrenches'
  Sent: Thursday, March 19, 2015 10:14 AM
  Subject: [RE-wrenches] Off grid loads Load sheet


  There is wide spread on the hot tubs. I have an offgrid client who bought a super-insulated (6-12" of foam) tub that heats the water with the waste heat from the (very inefficient) motor @ 120 vac. It went away when he was enlightened as to how it heated the water. I did not measure the load but it sank his battery bank.

  I have measured a few sat systems;  32-35 watts/hour about the same as a blue ray and DVD/CD player, & Routers at 4-12 watts/hr, answer mach @ 12-15 watts/hr with cordless phone charger charging, Garage door openers from 25-80 watts/hr depends on Manu, Motion detectors at 4-12 watts/hour depends on Manu.



  I have several watt hour meters I loan out for folks to do their "homework" on their loads before I do a design that helps & I see lots of variation on items.

  2 years ago in LA, I went into Costco with my Brand watt hour meter and 60" flat screens were pulling 65-83 watts. I was elated to find some real efficiency and a larger screen.

  I went in this last holiday season and ran the meter on the "NEW Smart" 60" flat screens and the lowest draw was 95+ watts and a lot were in the 125+ watt range. The new 60" flat screens come with a wireless keyboard and were full on computers with every cable and internet ready application you can imagine.



  ----------------------------------------------------------------------------

  Dana Orzel

  Great Solar Works, Inc -  NABCEP # 051112-136

  E - dana at solarwork.com  - Web - solarwork.com

  O - 970.626.5253  C - 208.721.7003 - No FAX Line

  "Responsible Technologies for Responsible People since 1988"

  P Please consider the environment before printing this email.





  From: RE-wrenches [mailto:re-wrenches-bounces at lists.re-wrenches.org] On Behalf Of frenergy
  Sent: Thursday, March 19, 2015 8:56 AM
  To: RE-wrenches
  Subject: [RE-wrenches] Load sheet



  Wrenches,



          I'm always trying to update my reference for KWhrs/day for various loads, especially as time marches on folks are of course wishing to power the latest gizmo with an off-grid system.  I can't seem to find very current info.  The days of going into search are certainly long gone with the advent of answering/cordless phones, satellite dishes, routers, security systems, etc...creating a heck-of-a  "phantom load" 24/7.



          Specifically, this time I'm hoping some of you have first-hand numbers on KWhrs/day for a propane fired hot tub (still has brains of some kind, ignition, pump(s), satellite dish for internet/TV and I'm not counting on-demand water heater as much of a load due to its intermittent use unless others have seen otherwise.  I've never taken the "kit" approach, hoping a cookie cutter sized system will fit a need, instead trying to really nail the consumption-production dance leaving room for expansion.



          If there is a favorite website anyone has for more current numbers (KWhrs/day or even just watts) on current household appliances, I would appreciate it.



  Thx,



  Bill Battagin

  Feather River Solar Electric
  4291 Nelson St.
  Taylorsville, CA  95983
  530.284.7849 / 6544 fax



------------------------------------------------------------------------------
