Good Day Wrenches,

Does anyone know of a 400 Amp Meter/Main that can accomplish the following?

1)  Provide 2 x 200 Main Breakers for Loads
2) Provide an easy supply side tap point for 160 Amps of Grid-tie Solar
(so basically a 200 Amp backfeed)

I'm considering using an Eaton 324 N
<https://www.rexelusa.com/p/525405/eaton-b-line/400a-4p-4-jaw-meter-socket/782051622102/324-n>
(Eaton B-Line 324 N 400A, 320 A cont. 4P, 4 Jaw, Meter Socket W Link
Bypass Facilities) but I'm not sure I can double lug it and then also
tap off of one of the 200 Amp lines with another tap (using Ilsco
IPC-250-4/0
<https://www.ilsco.com/Ilsco/ccrz__ProductDetails?sku=IPC-250-4%2F0-ILSM-ILS&cclcl=en_US>
splice connectors).

Thanks!

Jeff


~~~~~~~~~~~
