Mike,

Thanks for posting the note, but I find the wording to be less than fully
clear. According to this note, the "The transformer-less series of inverters
named Sunny Boy TL-US-12, Sunny Boy TL-US-22 and Sunny Tripower
12/15/20/24000TL-US-10 have a neutral connection that is required at
installation for instrumentation, voltage and phase detection only."

There is no mention of the -41 inverter also using the neutral for reference
only, even though the note is "applicable to the following inverter types"
and that shows the -41

Also, the table has these green x marks but no annotation of what the green
x indicates.

Can you clarify, please?
