[RE-wrenches] SMA US 7.7 T-L 41

[Harry Mahon]

Drake - that is indeed correct.

Spacing for the Connection Unit (CU) holes matches what was available in top holes of old mounting bracket. With those screws landing into studs, the unit will be sufficiently supported by the die-cast aluminum CU.

The only concern I have heard is an installer who mounted it to a horizontal Unistrut rail - the unit wanted to rotate around the rail. Having a rigid surface behind the unit will prevent this.

Also - please ensure the ribbon cable from the communications board in the CU that comes from the Power Unit (PU) upper part is detached at the communications board before separating the two halves.  All units are power tested at the factory so the connection is needed, but it is not disconnected upon shipment. I do not feel this required step is sufficiently clear in our manuals currently.

Best regards -
Mike



SMA America
Michael Mahon
Technical Trainer, Solar Academy
6020 West Oaks Boulevard, Suite 300
Rocklin, CA 95765
U.S.A.
Mobile:   +1 916 918 9412
www.SMA-America.com<http://www.sma-america.com/>

Solar Academy: www.SMA-America.com/partners/sma-solar-academy/overview.html<http://www.sma-america.com/partners/sma-solar-academy/overview.html>

Full training schedule: https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html


[http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/facebook.jpg]<http://www.facebook.com/pages/SMA-America/140290312717395>[http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/twitter.jpg]<http://twitter.com/SMA_America> [http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/wordpress.jpg] <http://www.smainverted.com/>  [Linkedin Logo] <http://www.linkedin.com/company/364675>  [http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/youtube.jpg] <http://www.youtube.com/playlist?list=PL840A5336CAC32332>  [SMAAFORUM_ICON] <http://smaadvance.com/signup/>
[cid:image008.jpg at 01D54D07.DC1BFFF0]<https://eur02.safelinks.protection.outlook.com/?url=https%3A%2F%2Fwww.sma-america.com%2Fhome-systems%2Fpv-solar-and-storage-solutions.html&data=02%7C01%7CMichael.Mahon%40sma-america.com%7Cc4bcd59d55584c70681208d71b72e485%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637008052588484449&sdata=itzAGcXAYe0xd5Zhzjuljm6dijJW%2FRGtItHrvxRkrTI%3D&reserved=0>


This email and any attachments thereto may contain SMA America, LLC confidential, privileged and private material for the sole use of the intended recipient. Any review, copying, or distribution of this email (or any attachments thereto) by others is strictly prohibited. If you are not the intended recipient, please contact the sender immediately and permanently delete the original and any copies of this email and any attachments thereto. Thank you.

From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Drake
Sent: Thursday, October 3, 2019 9:34 AM
To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
Subject: [RE-wrenches] SMA US 7.7 T-L 41

Hello Wrenches,

A TL-41 came instead of a TL -40. The mounting instructions say to use 2 screws on the conduit box under the inverter to hold up the entire unit Tech support is being  trained soon, but so far does not know.

[Emacs!]
Can this be right?

Thanks,

Drake
