[RE-wrenches] Sol-Ark Technical Question

[drake.chamberlin at redwoodalliance.org]

Hello Jharen,

Members of the RE Wrench list are still hoping for an answer to the
question of how to program a limit on the AC output of Sol-Ark
inverters. Can you send an explanation to me, to post on the list, or
post it yourself if you are able.

Thank you,

Drake

_Drake Chamberlin_

_Athens Electric LLC_

_Ohio Electrical Contractor's License 44810_

_NABCEP Certified PV Installation Professional_

---

On 2025-06-04 18:29, drake.chamberlin at redwoodalliance.org wrote:

> Hi Jharen,
>
> Paul Wood will be contacting you. We talked during the system redesign
> process. Paul is one of the physical installers of the system.
>
> This system has 9 Sol-Ark 15K inverters. Breakers are tripping on the
> input and output.
>
> Thank you,
>
> Drake
>
> _Drake Chamberlin_
>
> _Athens Electric LLC_
>
> _Ohio Electrical Contractor's License 44810_
>
> _NABCEP Certified PV Installation Professional_
>
> ---
>
> On 2025-06-04 17:03, Poole, Jharen via RE-wrenches wrote:
>
> Hello,
>
> I'd like to get this question resolved for you as quickly as possible.
> Could you please reach out to me at jharen.poole at sol-ark.com with the
> details of how much power or amperage you'd like to limit for this
> installation? Additionally, please include any relevant information
> about the inverter and its setup--such as inverter SN, whether it's
> configured for zero net metering or any other specific setup.
>
> Best Regards,
>
> Jharen Poole
> Applications Engineer II
> 972-575-8875
>
> -------------------------
>
> From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> on behalf
> of Jason Szumlanski via RE-wrenches <re-wrenches at lists.re-wrenches.org>
> Sent: Wednesday, June 4, 2025 10:10 AM
> To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
> Cc: Jason Szumlanski <jason at floridasolardesigngroup.com>; Wodenrobert23
> <wodenrobert23 at gmail.com>
> Subject: Re: [RE-wrenches] Sol-Ark Technical Question
>
> Caution: This email is from an external source.
>
> If I understand the question correctly, you can use Time of Use to set
> the maximum charge or sell power in watts for up to 6 time slots. I
> believe this will limit only the battery charge or discharge rate,
> however. I don't believe this will limit the total input (loads plus
> battery charging). You can limit the total sell power with the Grid
> Sell feature in the System Work Mode settings. The Max Sell Power
> should limit the total solar export plus battery selling to this
> setting.
>
> Jason Szumlanski
> Principal Solar Designer | Florida Solar Design Group
> NABCEP Certified Solar Professional (PVIP)
> Florida State Certified Solar Contractor CVC56956
> Florida Certified Electrical Contractor EC13013208
>
> On Wed, Jun 4, 2025 at 10:55 AM Drake Chamberlin via RE-wrenches
> <re-wrenches at lists.re-wrenches.org> wrote:
>
> Sol-Ark has not been available to answer a question.
>
> We need to reduce the AC amperage input and output on a system. Tech
> support had assured us that this can be done, prior to installing the
> system. It is unclear how to do this.
>
> Does anyone know how to adjust the AC in and AC out maximum amperage on
> the 15kW Sol-Ark inverters?
>
> --
>
> _Drake Chamberlin_
>
> _Athens Electric LLC_
>
> _Ohio Electrical Contractor's License 44810_
>
> _NABCEP Certified PV Installation Professional_
>
> --
