I''ve got multiple Q.Cell 235 watt module sites with the same issue and
some are even shattering. Noticed it on a Canadian Solar project from 2014
as well. I don't care that the new products are entirely different and
produced at different facilities, I'll never use products from either
manufacturer again.
Nick
On Fri, Jan 24, 2025 at 2:32 PM David Buckner via RE-wrenches <
re-wrenches at lists.re-wrenches.org> wrote:
> Following up on this, the manufacturer has stated that this is a known
> issue for a run of modules they had back in the summer of 2012. It’s
> called chalking and the back sheets are degrading faster than what is
> typical, and unfortunately these modules are out of their 10 year
> workmanship warranty. Eventually the glass breaks and the performance
> drops but you cannot make a performance warranty claim on a damaged
> module. So essentially the manufacturer appears to have waited until the
> 10 year workmanship warranty was up before notifying customers about this
> issue leaving them with no options.
>
>
>
> David Buckner
>
> President
>
> Solar Energy Systems
>
> 917-848-0215
>
> 718-389-1545
>
> dbuckner at solaresystems.com
>
> www.solaresystems.com
> <https://us.content.exclaimer.net/?url=https%3A%2F%2Fwww.solaresystems.com%2F&tenantid=sjl0rdWaEe6F-WBFvdNAXQ&templateid=933619bad6e2ee11aaf06045bdd55b16&excomponentid=W0znjuLBICxfJOZwpEisk1w6Uz7kRcz8RFh31bsCZu4&excomponenttype=Link&signature=oLHGWCDHeQYPxuVijopczXguVIz2A9gWA29emAtwvdbqV2XsAnsbVfPJR3OQHtcxck-4zeNWEHrxwAX_LXCUOBXnvLDZkSB3Ue09sLzQcUNKGxMLclBt5peel7iiM1neHKnk8UctTRnOeUfIagifjZaGWicP4Wi23eUaL-JSNh0iUlYWH5Y2kOEt_QGU-R6LtdhPzR8aNOqjq8ttGuksaSFX3YQorUNiBDkXDGXmmCSiiNgljGMekvYiEvoXMsCe_CC1DpnfHsaH45ZBD8L442uACHbkOuyDJ-IG20zpBYXGK3TzDh-GW4efLwZfi6MUcJohrIgQQag5JDhSynWoDQ&v=1&imprintMessageId=e8f99903-6e51-4797-aec9-99b594002d97>
>
> 41 Box Street 2nd Floor, Brooklyn, NY 11222
>
> The information contained in this email message, including any attached
> files transmitted, is confidential and may be legally privileged. It is
> intended for the sole use of the individual(s) named above. If you are the
> intended recipient, be aware that your use of any confidential or personal
> information may be restricted by state and federal privacy laws. If you,
> the reader of this message, are not the intended recipient, you are hereby
> notified that you should not further disseminate, distribute or forward
> this email message. Email transmission cannot be guaranteed to be secured
> or error-free as information could be intercepted, corrupted, lost,
> destroyed, arrive late or incomplete, or contain viruses. The sender
> therefore does not accept liability for any errors or omissions in the
> contents of this message, which arise as a result of this e-mail
> transmission. If you have received this email in error, please notify the
> sender and immediately delete the material from your computer system. Thank
> you.
>
> *From:* David Buckner
> *Sent:* Monday, January 13, 2025 12:14 PM
> *To:* 'RE-wrenches' <re-wrenches at lists.re-wrenches.org>
> *Subject:* 13 YR Old Modules with cracking backsheets
>
>
>
> Hi All,
>
>
>
> We have discovered quite a few modules at a particular site that are
> showing cracking in the back sheets. It appears these modules are not
> underperforming yet, but we assume it’s a matter of time before they all
> water and start causing the glass to shatter. Some of the modules at this
> site are at that shattered glass stage. I’m assuming we should thermal
> image and keep an eye on potential hotspots, but any other advice would be
> great to hear. Full removal isn’t out of the question, but this is about
> 40% of a 1MW rooftop system.
>
>
>
>
