[RE-wrenches] Oddball wire request
frenergy
frenergy at psln.com
Thu Oct 10 07:19:49 PDT 2013
Alan,
At 53 watts, we're not talking about much in the way of amps....I don't even know but isn't there a 14 or even 16 gauge that would have the OD you're looking for and still carry the current, easily, with short runs to a combining j-box. I just found some 14 gauge at Nassua Electrical, .2" OD.
Just a thought.
Bill Battagin
----- Original Message -----
From: <penobscotsolar at midmaine.com>
To: <Allan at positiveenergysolar.com>; "RE-wrenches" <re-wrenches at lists.re-wrenches.org>
Sent: Thursday, October 10, 2013 3:52 AM
Subject: Re: [RE-wrenches] Oddball wire request
> Hi Allan,
> Is it possible to use 1/2" carflex connectors and nm carflex from panel
> to panel? You could then use THWN anywhere you wanted. This is what we
> used to do with all our systems back in the day....
>
> Daryl
>
>
>> <html>
>> <head>
>>
>> <meta http-equiv="content-type" content="text/html;
>> charset=ISO-8859-1">
>> </head>
>> <body text="#000000" bgcolor="#FFFFFF">
>> Wrenches,<br>
>> I do a fair amount of work on ancient systems, just because there's
>> been off grid here for decades. I'm rewiring several old arrays for
>> my next door (meaning < 1/4 mile away) neighbor. The particular
>> array has six 53W Solec modules wired as three two-module 24V pairs,
>> on a Zomeworks tracker so old that it has aluminum rails and
>> attached freon canisters instead of the integral square tubes. Both
>> modules and tracker continue to work well, but the wiring is so
>> degraded from sun exposure that's it's bare in spots, and this is
>> what I want to fix.<br>
>> <br>
>> Each module has a tiny j-box - 3" x 3" x 7/8" deep. Each j-box has a
>> single 3/8" cord grip bushing (CGB). Each bushing has two #10
>> conductors coming out of the single hole in the CGB. The O.D. of
>> each wire is about the same as that of THWN. The problem is that the
>> single hole in the CGB is only large enough to fit this diameter.
>> USE-2 is too large, and modern PV wire is way too large. <br>
>> <br>
>> I bought a dozen replacement 3/8" CGBs from Del City, but the
>> matching lock rings are too large to fit inside the j-boxes. I'd be
>> cautious about using a narrow Unibit to drill an additional hole in
>> each j-box anyway, given that the holes would be so close to the
>> backsheet. <br>
>> <br>
>> The easiest solution would be to find some sunlight-resistant,
>> wet-rated single-conductor wire in #10 or #12 that has an insulation
>> O.D. about the same as THHN/THWN. Any ideas, please? Code is not an
>> issue in this instance - I just want a solution that works.<br>
>> <br>
>> I thought about using float switch cable, which is UV-resistant,
>> wet-rated, direct-burial-rated type TC. We keep plenty in stock for
>> signal circuits, and it fits and is strong. The problem is that I
>> need single conductors, because each module will have one series
>> conductor and one output conductor, and they run to different
>> locations. <br>
>> <br>
>> Are there any better ideas out there?<br>
>> Thanks, Allan<br>
>> <div class="moz-signature">-- <br>
>> <meta http-equiv="Content-Type" content="text/html;
>> charset=ISO-8859-1">
>> <meta name="ProgId" content="Word.Document">
>> <meta name="Generator" content="Microsoft Word 11">
>> <meta name="Originator" content="Microsoft Word 11">
>> <link rel="File-List" href="SignatureNew_files/filelist.xml">
>> <o:smarttagtype
>> namespaceuri="urn:schemas-microsoft-com:office:smarttags"
>> name="address">
>> <o:smarttagtype
>> namespaceuri="urn:schemas-microsoft-com:office:smarttags"
>> name="PostalCode">
>> <o:smarttagtype
>> namespaceuri="urn:schemas-microsoft-com:office:smarttags"
>> name="State">
>> <o:smarttagtype
>> namespaceuri="urn:schemas-microsoft-com:office:smarttags"
>> name="City">
>> <o:smarttagtype
>> namespaceuri="urn:schemas-microsoft-com:office:smarttags"
>> name="Street">
>> <!--[if gte mso 9]><xml>
>> <o:DocumentProperties>
>> <o:Author>pe</o:Author>
>> <o:Template>Normal</o:Template>
>> <o:LastAuthor>pe</o:LastAuthor>
>> <o:Revision>6</o:Revision>
>> <o:TotalTime>2</o:TotalTime>
>> <o:Created>2013-06-07T19:15:00Z</o:Created>
>> <o:LastSaved>2013-09-23T20:34:00Z</o:LastSaved>
>> <o:Pages>1</o:Pages>
>> <o:Words>69</o:Words>
>> <o:Characters>394</o:Characters>
>> <o:Company>pe</o:Company>
>> <o:Lines>3</o:Lines>
>> <o:Paragraphs>1</o:Paragraphs>
>> <o:CharactersWithSpaces>462</o:CharactersWithSpaces>
>> <o:Version>11.9999</o:Version>
>> </o:DocumentProperties>
>> </xml><![endif]--><!--[if gte mso 9]><xml>
>> <w:WordDocument>
>> <w:SpellingState>Clean</w:SpellingState>
>> <w:GrammarState>Clean</w:GrammarState>
>> <w:ValidateAgainstSchemas/>
>> <w:SaveIfXMLInvalid>false</w:SaveIfXMLInvalid>
>> <w:IgnoreMixedContent>false</w:IgnoreMixedContent>
>> <w:AlwaysShowPlaceholderText>false</w:AlwaysShowPlaceholderText>
>> <w:Compatibility>
>> <w:UseFELayout/>
>> </w:Compatibility>
>> <w:BrowserLevel>MicrosoftInternetExplorer4</w:BrowserLevel>
>> </w:WordDocument>
>> </xml><![endif]--><!--[if gte mso 9]><xml>
>> <w:LatentStyles DefLockedState="false" LatentStyleCount="156">
>> </w:LatentStyles>
>> </xml><![endif]--><!--[if !mso]><object
>> classid="clsid:38481807-CA0E-42D2-BF39-B33AF135CC4D" id=ieooui></object>
>> <style>
>> st1\:*{behavior:url(#ieooui) }
>> </style>
>> <![endif]-->
>> <style>
>> <!--
>> /* Font Definitions */
>> @font-face
>> {font-family:"MS Mincho";
>> panose-1:2 2 6 9 4 2 5 8 3 4;
>> mso-font-alt:"\FF2D\FF33 \660E\671D";
>> mso-font-charset:128;
>> mso-generic-font-family:modern;
>> mso-font-pitch:fixed;
>> mso-font-signature:-1610612033 1757936891 16 0 131231 0;}
>> @font-face
>> {font-family:"\@MS Mincho";
>> panose-1:2 2 6 9 4 2 5 8 3 4;
>> mso-font-charset:128;
>> mso-generic-font-family:modern;
>> mso-font-pitch:fixed;
>> mso-font-signature:-1610612033 1757936891 16 0 131231 0;}
>> /* Style Definitions */
>> p.MsoNormal, li.MsoNormal, div.MsoNormal
>> {mso-style-parent:"";
>> margin:0in;
>> margin-bottom:.0001pt;
>> mso-pagination:widow-orphan;
>> font-size:12.0pt;
>> font-family:"Times New Roman";
>> mso-fareast-font-family:"MS Mincho";
>> color:black;}
>> a:link, span.MsoHyperlink
>> {color:blue;}
>> a:visited, span.MsoHyperlinkFollowed
>> {color:blue;}
>> span.SpellE
>> {mso-style-name:"";
>> mso-spl-e:yes;}
>> @page Section1
>> {size:8.5in 11.0in;
>> margin:1.0in 1.25in 1.0in 1.25in;
>> mso-header-margin:.5in;
>> mso-footer-margin:.5in;
>> mso-paper-source:0;}
>> div.Section1
>> {page:Section1;}
>> -->
>> </style><!--[if gte mso 10]>
>> <style>
>> /* Style Definitions */
>> table.MsoNormalTable
>> {mso-style-name:"Table Normal";
>> mso-tstyle-rowband-size:0;
>> mso-tstyle-colband-size:0;
>> mso-style-noshow:yes;
>> mso-style-parent:"";
>> mso-padding-alt:0in 5.4pt 0in 5.4pt;
>> mso-para-margin:0in;
>> mso-para-margin-bottom:.0001pt;
>> mso-pagination:widow-orphan;
>> font-size:10.0pt;
>> font-family:"Times New Roman";
>> mso-fareast-font-family:"Times New Roman";
>> mso-ansi-language:#0400;
>> mso-fareast-language:#0400;
>> mso-bidi-language:#0400;}
>> </style>
>> <![endif]--><!--[if gte mso 9]><xml>
>> <o:shapedefaults v:ext="edit" spidmax="5122"/>
>> </xml><![endif]--><!--[if gte mso 9]><xml>
>> <o:shapelayout v:ext="edit">
>> <o:idmap v:ext="edit" data="1"/>
>> </o:shapelayout></xml><![endif]-->
>> <div class="Section1">
>> <p class="MsoNormal"><b>Allan <span
>> class="SpellE">Sindelar</span></b><br>
>> <span style="font-size:10.0pt"><a
>> href="mailto:Allan at positiveenergysolar.com"><u><span
>> style="color:#000099">Allan at positiveenergysolar.com</span></u></a></span><br>
>> <span style="font-size:10.0pt">NABCEP Certified PV
>> Installation Professional<br>
>> NABCEP Certified Technical Sales Professional<br>
>> New Mexico EE98J Journeyman Electrician<br>
>> Founder, <b>Positive Energy,
>> Inc.<o:p></o:p></b></span></p>
>> <p class="MsoNormal"><span style="font-size:10.0pt">A
>> Certified B <span
>> class="SpellE">Corporation<sup><span
>> style="font-size:7.5pt">TM</span></sup></span><br>
>> <st1:address w:st="on"><st1:street w:st="on">3209
>> Richards Lane</st1:street><br>
>> <st1:city w:st="on">Santa Fe</st1:city>,
>> <st1:state
>> w:st="on">New Mexico</st1:state> <st1:postalcode
>> w:st="on">87507</st1:postalcode></st1:address><br>
>> <b>505 424-1112 office 780-2738 cell</b><br>
>> <a href="http://www.positiveenergysolar.com/"
>> target="_blank"><u>www.positiveenergysolar.com</u></a><o:p></o:p></span></p>
>> <p class="MsoNormal"><span
>> style="font-size:10.0pt"><span
>> style="mso-spacerun:yes"> </span></span></p>
>> </div>
>> </o:smarttagtype></o:smarttagtype></o:smarttagtype></o:smarttagtype></o:smarttagtype></div>
>> </body>
>> </html>
