[RE-wrenches] Ideas and racking systems for "stowing" ground mount PV array during snowy winter?

[Jeff Clearwater]

Coming back to this Blake - seems to me you need a platform type rack
that has a tilt-up set of legs.

The Nuance Osprey is such a rack - though I think they only go up to 35º
but I think it could be easily adapted.  They use Earth Anchors but can
also be mounted to sonotubes or even ground screws.

It's beefy strong - no aluminum - just might work with heavy snow.

https://nuanceenergy.com/solar-products/osprey-powerplatform

It's possible having two in portrait makes for too high a vertical but
perhaps using 60 cell modules instead of 72 might make it workable.

Just a thought - hope it helps!

Best,

~~~~~~~~~~~
Jeff Clearwater

linkedin <https://www.linkedin.com/in/jeff-clearwater-0622a312/>
www.villagepowerdesign.com <http://www.villagepowerdesign.com>
cell - 413-559-9763
~~~~~~~~~~~~~~~~~~~~~~~






> Blake Gleason via RE-wrenches <mailto:re-wrenches at lists.re-wrenches.org>
> March 26, 2022 at 8:39 AM
> Hi all,
>
> I think there's a lot of experience on this list with PV in snowy regions.
>
> I'm wondering if anyone has ideas and/or specific hardware/racking
> systems to allow for easy "stowing" (in vertical or near-vertical
> position) or "seasonal removal" of the ground mount PV modules for the
> winter (snow) season?  Or ideas for a completely different approach to
> solving the challenge I'm facing?
>
> I'm planning a new off-grid system in the Sierra (around 6000') for a
> small commercial community center facility.  The facility is
> accessible and in use only during the summer months.  So, I want to
> optimize production for the summer, and also avoid having the array
> destroyed by the heavy Sierra snow during the winter.
>
> To further paint the picture, here are some more details and constraints:
>
> - System size: 23kW (likely 48 Silfab 490 mods)
> - Must be ground mount (beautiful very tall trees completely
> surrounding all roof options)
> - Must be relatively low profile, visually.  Pole mount not an option
> - Ideally one clean rectangular array 4x12 mods (13' x 90') or two 4x6
> arrays (13' x 45')
> - Array tilt: 10-15 deg (summer use only, must be low-profile)
>
> There is a caretaker who has a seasonal crew, and could be trained to
> "stow" the array each season as long as that process is relatively
> straightforward.
>
> At one end of the spectrum, it could be as simple as disconnecting and
> un-installing all of the modules to store them in a stack underneath
> the nearby deck for the winter.  I'd like to think there might be a
> more "elegant" solution (and less labor intensive, and less wear and
> tear on the modules over the years).  I wondered if there's a clever
> way to "drop" the modules to a near-vertical orientation so they could
> remain in place during the winter (some kind of hinge at the top and
> release at the bottom).  I guess this might require individual rows of
> modules instead of one large array.
>
> (As a bonus, I'd like to keep about four mods (out of the 48)
> operational through the winter for battery maintenance and a few
> incidental loads.  These could be vertically mounted on the south side
> of one of the buildings, above the typical snow drift level, for example.)
>
> Thanks in advance for any suggestions, ideas, things you've tried that
> haven't worked, etc!!
>
> Best,
> Blake
>
> --
>
> Blake Gleason, PE | Employee Owner
> Director of Innovation and Technical Excellence
> O: 510-845-2997 x128
> C: 510-867-5878
>
> 1035 Folger Ave.
> Berkeley, CA 94710
> www.sunlightandpower.com <http://www.sunlightandpower.com>
> License #326203
>
>
>
