[RE-wrenches] Conext XW Pro Compatible Generators?

[Jay]

Hi Jeff

The generator is not set up for 2 wire remote.

The two options that I know of are the one I sent you which converts the remote to 2 wire.
Disadvantage of this one is that it will only attempt the start 1 time. But that generator on gasoline seems to start every time first time.  Propane conversion not.

Or the factory unit which like this one.

https://www.electricgeneratorsdirect.com/Honda-32380-Z37-820ZA/p65440.html?gclid=CjwKCAiAxJSPBhAoEiwAeO_fP1IhOE5lCjwjD81BLmbvGVudBjZaJN_siF2UiT4xbNe9uhGxusSlWxoCEKsQAvD_BwE

The advantage of this one is that it follows the inverter ags start programming so you get 3 attempts if memory serves.
But you’ve got to figure out the correct ags protocol on the Xw.

Hope this helps

Jay



> On Jan 17, 2022, at 1:38 PM, Jeff Clearwater <jeffc at villagepowerdesign.com> wrote:
>
>  Thanks Michael and Jay!
>
> If the generator is a 2-wire start why is there the need for additional remote start relays?  Does the Honda not come fully equipped?  And if not is there a generator that does?
>
> Thanks,
>
> Jeff
>
>> Michael Morningstar January 17, 2022 at 12:01 PM
>> Conext AGS can be set up for almost any remote start/stop configuration. Honda eu7000i with remote start relays from GeneratorLine.
>>
>>
>>
>>
>>
>>
>> 	Michael Morningstar
>>
>>      	Morningstar Electric
>> 	PO Box 1494
>> 	Mount Shasta, California 96067
>> 	530-921-0560
>> 	CSLB 949635
>>
>>
>>
>> Jeff Clearwater January 17, 2022 at 10:18 AM
>> Good Day Wrenches,
>>
>> So can anyone steer me to generator models in the 5-7 KW range (gas) that are known compatible with the Conext XW Pro and the Conext AGS module?
>>
>> Thanks!
>>
>> Jeff
>>
>> ~~~~~~~~~~~
>> Jeff Clearwater
>>
>> www.villagepowerdesign.com
>> cell - 413-559-9763
>>
>>
>>
>>
>>
