Jason -

Yes, it's definitely a violation of 110.26 to have batteries/enclosures
below things like panelboards if the batteries stick out more than 6" past
the face of the panelboards (etc).  Specifically, it would be a violation
of 110.26(A), which is distinct from 110.26(E) (the section that addresses
"other systems" such as ducts, etc).  110.26(A) is all about providing a
safe "working space" for an electrician to maintain the panelboard,
disconnect, etc without having to reach over or around other equipment (of
any kind), which would put the electrician in a compromised position when
maintaining potentially energized equipment.
Additionally, the 6" allowance granted by 110.26(A)(3) is only valid if the
batteries are "associated" with the electrical installation (which they
would be, if the panelboards and other equipment whose working space is
being infringed upon are related to the batteries).

When we are pressed for space, we have built out the wall above the
batteries so that the face of the panelboards, etc are within 6" of the
outside face of the battery enclosure(s).  One example is attached here
(with three Powerwalls stacked).

Best,
Blake
