Hi Jason,

You were asking for 60KWH of storage, it has to go somewhere
and fit. Too me, that is a ridiculous amount of storage and sounds like
someone with an all electric kitchen and laundry, 4 ton ac units, +++.


The system pix attached can add 20 of these 6.7 KWH useable AES
batteries, but much easier to choose the right appliances.

I realize that
I am assuming here, I do get requests like that so do not take this wrong!


Dave Angelini Offgrid Solar
"we go where powerlines
don't"
http://members.sti.net/offgridsolar/ [1]
e-mail offgridsolar at sti.net
[2]
text 209 813 0060

On Sun, 31 Jan 2021 14:27:48 -0500, Jason Szumlanski
wrote:     I'm seeing a lot of pictures of LiPO battery systems and people
are mounting equipment above them like load centers, inverters with
disconnects, and other serviceable enclosures. Some of these battery
systems are 24 inches deep or more. This seems to violate NEC 110.26
requirements for the other serviceable equipment, but the pictures are
proudly displayed as models of success. Even slender Tesla Powerwalls stick
out significantly when stacked 2 or 3 deep and would be more than 6 inches
deeper than a standard load center. Sure, the battery cabinets make great
places to rest tools while working, but does anyone else see this as
problematic?    Jason Szumlanski Florida Solar Design Group
