[RE-wrenches] Stackable Battery-Based systems complying to IEEE 1547-2018 standard

[Harry Mahon]

Dave –
Related but different.

CA Rule 21 and HECO Rule 14H and NE-ISO require equipment tested to UL1741 SA (which outlines what additional functions beyond UL1741 inverters must be capable of) utilizing the appropriate utility Source Requirement Document (SRD).  The SRD spells out which UL 1741 SA additional functions  -with set point values-  each utility wants enabled .  This allows for “smart inverter” functionality to prevent undesirable behavior.

The objective of the IEEE 1547.x updates is to harmonize testing across the industry to provide a uniform baseline for “smart” inverter functionality/capability.  I believe there will still be specific SRDs – that is, not all tested IEEE 1547-2018 functionality will be enabled by default.

I vaguely remember hearing of deadline for certification being at most 18 months after publishing of the standard (which I think means the IEEE1547.1-2020 standard as that actually outlined the testing procedures for listing), which would very roughly be Jan 2022.

Also, I think “Hawaii” is being very aggressive with this deadline  – I think they (HECO?  HELCO? Other?) have set July 1, 2021 as testing deadline?  Anyone have more details?

Mike

SMA America
Michael Mahon
Technical Trainer, Solar Academy
6020 West Oaks Boulevard, Suite 300
Rocklin, CA 95765
U.S.A.
Mobile:   +1 916 918 9412
www.SMA-America.com<http://www.sma-america.com/>

Solar Academy: https://solaracademy.sma.de/en.html

SMA America Solar Academy webinars: https://solaracademy.sma.de/en/courses.html
Choose "United States"
[A picture containing drawing, food  Description automatically generated]<https://eur02.safelinks.protection.outlook.com/?url=https%3A%2F%2Fwww.sma-america.com%2FShadeFix&data=02%7C01%7CMichael.Mahon%40sma-america.com%7Ceb737bd7586646b4d14b08d811405661%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637278315315432372&sdata=uyZ5K7ayyl6y%2Fa90qQ0%2F4r8WSV0PYLK1CYMJQxPVeCQ%3D&reserved=0>

[Linkedin Logo]<http://www.linkedin.com/company/364675> [cid:image003.jpg at 01D67C53.80A512C0] <http://www.youtube.com/playlist?list=PL840A5336CAC32332>  [SMAAFORUM_ICON] <http://smaadvance.com/signup/>  Follow, Like, Share

This email and any attachments thereto may contain SMA America, LLC confidential, privileged and private material for the sole use of the intended recipient. Any review, copying, or distribution of this email (or any attachments thereto) by others is strictly prohibited. If you are not the intended recipient, please contact the sender immediately and permanently delete the original and any copies of this email and any attachments thereto. Thank you.

From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Dave Angelini Offgrid Solar
Sent: Thursday, August 27, 2020 8:19 AM
To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
Subject: Re: [RE-wrenches] Stackable Battery-Based systems complying to IEEE 1547-2018 standard


Is IEEE 1547.1-2020 related to the issue in Hawaii  (HEICO) too much solar and cloud events that cause the transients? RULE 21 in California kind of thing? Or, it it different please?



Dave Angelini Offgrid Solar

"we go where powerlines don't"

http://members.sti.net/offgridsolar/<https://eur02.safelinks.protection.outlook.com/?url=http%3A%2F%2Fmembers.sti.net%2Foffgridsolar%2F&data=02%7C01%7Cmichael.mahon%40sma-america.com%7Cef932f50809b4d60b19408d84a943173%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637341347646941703&sdata=LMUx5jH6uRLvC6bNDqTN1oBIRg6tZZzpJdn5js0VYbY%3D&reserved=0>

e-mail  offgridsolar at sti.net<mailto:offgridsolar at sti.net>

text 209 813 0060
