[RE-wrenches] Rapid Shutdown Compliance

Thu Apr 30 13:28:13 EDT 2020

Dave – you may be referring to a product from Maxim Integrated to replace bypass diodes.  I have not heard much recently about this, but it did sounds promising.

And related to MLPE continuing to be required due to 2017 NEC 690.12, I believe UL 3741 will be published within a few months.  This will allow products (likely racking and certain module types) to be listed as a PV Hazard Control Array.  That listing will satisfy the Inside the Array Requirement 690.12 B(2)(1), thus avoiding the 80V limit of 690.12 B(2)(2).

I assume racking manufacturers will go after this listing (and pay the cost) as they can sell for a good markup as they can justify how much cost they will save by not requiring MLPE devices.

Mike

SMA America
Michael Mahon
Technical Trainer, Solar Academy
6020 West Oaks Boulevard, Suite 300
Rocklin, CA 95765
U.S.A.
Mobile:   +1 916 918 9412
www.SMA-America.com<http://www.sma-america.com/>

Solar Academy: https://solaracademy.sma.de/en.html

SMA America Solar Academy webinars: https://solaracademy.sma.de/en/courses.html
Choose "United States"
[SMA-POWERPLUS_EmailBanner-200910]<https://eur02.safelinks.protection.outlook.com/?url=https%3A%2F%2Fwww.sma-america.com%2Fsma-powerplus-solution.html&data=02%7C01%7CMichael.Mahon%40sma-america.com%7C47eae501cb0441233c9608d7c51babd8%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637194594948354114&sdata=1TFlz0P3UBA23LT%2BapAlWTb29kg%2FUcMbr36TERJpvqI%3D&reserved=0>

[Linkedin Logo]<http://www.linkedin.com/company/364675> [cid:image003.jpg at 01D61EE2.00170880] <http://www.youtube.com/playlist?list=PL840A5336CAC32332>  [SMAAFORUM_ICON] <http://smaadvance.com/signup/>  Follow, Like, Share

This email and any attachments thereto may contain SMA America, LLC confidential, privileged and private material for the sole use of the intended recipient. Any review, copying, or distribution of this email (or any attachments thereto) by others is strictly prohibited. If you are not the intended recipient, please contact the sender immediately and permanently delete the original and any copies of this email and any attachments thereto. Thank you.

From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Dave Tedeyan
Sent: Thursday, April 30, 2020 10:22 AM
To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
Subject: Re: [RE-wrenches] Rapid Shutdown Compliance

I was told at a training a couple years ago that there were going to be some modules coming out soon that had a microchip in the module junction box which would replace the diodes and effectively work as MLPE. I have not heard anything about that recently though. Does anyone know what I am talking about? It seems that this would solve many of the issues associated with MLPE, but still be able to have the benefits.
Cheers,
Dave

Dave Tedeyan, PE
Senior Engineer | Taitem Engineering, PC
[https://www.taitem.com/signatures/logo.png]
110 South Albany Street | Ithaca, NY 14850
o. 607.277.1118 x121  f. 607.277.2119
www.taitem.com<https://eur02.safelinks.protection.outlook.com/?url=http%3A%2F%2Fwww.taitem.com%2F&data=02%7C01%7Cmichael.mahon%40sma-america.com%7C4a353fcf348640107f7208d7ed22989a%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637238605161122551&sdata=ALhvsHj0OdfXxBgrSWMcFptZyu%2Bj9UfEqPxLKfsIs04%3D&reserved=0>

Solar • Sustainability • Energy • Design
Certified B-Corporation since 2013

On Thu, Apr 30, 2020 at 11:54 AM Dan Fink <danbob88 at gmail.com<mailto:danbob88 at gmail.com>> wrote:
Since I only work with off-grid systems, I find the 690.12 exception starting in NEC 2017 for ground-mounted systems with DC equipment in a separate structure intended only for PV components, is very useful for avoiding expensive, unneeded RSS equipment. Many folks don't like the idea of a battery bank and buzzing equipment and fans in their dwelling anyway, so the "power shed" idea works well, and around here structures 120 square feet and under don't need building permits. I did see one system pass with 3 PV modules on the roof of the power shed, though technically that's not part of the 690.12 exception.

Dan Fink
Owner, Buckville Energy Consulting
NABCEP Certified PV System Inspector
IREC Certified Instructor™ for:
~ PV Installation Professional
~ Small Wind Installer
NABCEP Registered Continuing Education Providers
d<mailto:dan.fink at greendustrialtraining.com>anbob88 at gmail.com<mailto:anbob88 at gmail.com>
970-672-4342
