Dave – Definitely hard to find a transformer based inverter these days.

If looking for a SB 6000US (this is not an endorsement by SMA), you can look at Solar Cowboyz and their new division, You Love Solar. They have SB 6000US listed on the website:
https://you-love-solar.myshopify.com/

Please pay attention to their note that the unit DOES NOT have AFCI and does not include a DC disconnect (though they appear to have those as well)

If you go that route, and if the SP modules require positive grounding, ensure you swap the GFDI fuse holders and set the jumper correctly as negative grounding was the factory default setup.

Best regards –
Mike


SMA America
Michael Mahon
Technical Trainer, Solar Academy
6020 West Oaks Boulevard, Suite 300
Rocklin, CA 95765
U.S.A.
Mobile:   +1 916 918 9412
www.SMA-America.com<http://www.sma-america.com/>

Solar Academy: www.SMA-America.com/partners/sma-solar-academy/overview.html<http://www.sma-america.com/partners/sma-solar-academy/overview.html>

Full training schedule: https://www.sma-america.com/partners/sma-solar-academy/seminars/trainings/training/list.html


[http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/facebook.jpg]<http://www.facebook.com/pages/SMA-America/140290312717395>[http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/twitter.jpg]<http://twitter.com/SMA_America> [http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/wordpress.jpg] <http://www.smainverted.com/>  [Linkedin Logo] <http://www.linkedin.com/company/364675>  [http://sma-planet.sma.de/fileadmin/fm-dam/infos/social_media/youtube.jpg] <http://www.youtube.com/playlist?list=PL840A5336CAC32332>  [SMAAFORUM_ICON] <http://smaadvance.com/signup/>
[cid:image008.jpg at 01D54D07.DC1BFFF0]<https://eur02.safelinks.protection.outlook.com/?url=https%3A%2F%2Fwww.sma-america.com%2Fhome-systems%2Fpv-solar-and-storage-solutions.html&data=02%7C01%7CMichael.Mahon%40sma-america.com%7Cc4bcd59d55584c70681208d71b72e485%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637008052588484449&sdata=itzAGcXAYe0xd5Zhzjuljm6dijJW%2FRGtItHrvxRkrTI%3D&reserved=0>


This email and any attachments thereto may contain SMA America, LLC confidential, privileged and private material for the sole use of the intended recipient. Any review, copying, or distribution of this email (or any attachments thereto) by others is strictly prohibited. If you are not the intended recipient, please contact the sender immediately and permanently delete the original and any copies of this email and any attachments thereto. Thank you.

From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Dave Tedeyan
Sent: Monday, October 14, 2019 12:21 PM
To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
Subject: [RE-wrenches] SPR-5200 inverter parts

Hi All,
I believe this was also a PV Powered rebranded inverter.
I have someone with one of these inverters which has stopped working. It appears that when it has AC voltage on the terminals in the inverter, there is no voltage on the wires that go to the transformer in the upper part of the inverter. Has anyone experienced this, and would a replacement board fix the issue? And would anyone have anything like that available?

And if not, can anyone even get a grounded inverter these days? Sunpower tells me to get a SB6000US, but I cannot even find one of those.

Thanks,
Dave

Dave Tedeyan, PE
Senior Engineer | Taitem Engineering, PC
[https://www.taitem.com/signatures/logo.png]
110 South Albany Street | Ithaca, NY 14850
o. 607.277.1118 x121  f. 607.277.2119
www.taitem.com<https://eur02.safelinks.protection.outlook.com/?url=http%3A%2F%2Fwww.taitem.com&data=02%7C01%7Cmichael.mahon%40sma-america.com%7C241148baad5642f7c75f08d750d34035%7Ca059b96c28294d1188374cc1ff84735d%7C0%7C0%7C637066740570285691&sdata=%2F1lcgapkHSk97ZvCkDAbAfPdEbx41oc%2B9ITuWFBpluk%3D&reserved=0>

Solar • Sustainability • Energy • Design
B-Corporation Best for the World 2018 Honoree
