[RE-wrenches] RSS: Is it necessary?
David Buckner
dbuckner at solaresystems.com
Tue Feb 18 17:15:01 PST 2025
We are either using Solar Edge or designing and procuring to UL3741 to meet rapid shut down without MLPE. Be careful cost wise with larger roofs where the AC runs from inverters that are far away and next to their subarray are resulting in larger wire sizes. Still, it’s worth it to sleep a little better at night.
The manufacturers of MLPE’s were justifiably not ready to deliver safe products to the industry at the scale needed. Is there a product that will safely last 25 years under these conditions? 90+ degrees on the roof that day and 20 degrees out there today. I always remember John Wiles saying forget about the modules working for 25 years, worry about the BOS. And for the most part that’s generally accurate.
In our specific fire last year:
1. Firefighters didn’t go on the roof (and they apparently do not in such situations here) but rather sprayed it from two separate locations.
2. Firefighters didn’t shut off the solar AC disconnect which was external and accessible. Eventually it was shut off by the owner when they realized the system was still operating.
3. The next morning when the sun came up and the damaged array started arcing and burning, they sprayed it for another couple of hours.
4. After a structural engineer inspected the decking, we were finally allowed on the roof to make the situation as safe as possible electrically which consisted of isolating down to every module in damaged areas and every string that wasn’t damaged. Otherwise the damaged RSDs weren’t making anything safer.
5. Investigation by multiple insurance companies’ fire expert teams followed but not for two weeks.
6. The teams knew each other from chasing these types of fires across the country and they had a nickname for the RSD on this roof.
7. $3M in damage was the last number I heard. Thankfully no immediate injuries, other than psychological, but that smoke is absolutely horrible.
8. Here is a link to the fire: https://www.google.com/search?q=roof+fire+secaucus+NJ&rlz=1C1ASVC_enUS948US955&oq=roof+fire+secaucus+NJ&gs_lcrp=EgZjaHJvbWUyBggAEEUYOTIHCAEQIRigATIHCAIQIRigATIHCAMQIRigATIHCAQQIRigATIHCAUQIRirAtIBCDUwNjZqMGo0qAIAsAIB&sourceid=chrome&ie=UTF-8#fpstate=ive&vld=cid:2ee587e2,vid:7Vw-5alnbKM,st:0
We’re seeing insurance companies sending questionnaires out to our PV system owners asking about maintenance agreements, type of equipment, etc. One of the questions inevitably is whether there are module level shut down devices installed. I wonder who is helping them out with that questionnaire. And at some point will the presence of MLPE’s be viewed as positive or negative when writing the insurance policy for that building?
David
David Buckner
President
Solar Energy Systems
917-848-0215
718-389-1545
dbuckner at solaresystems.com
www.solaresystems.com
41 Box Street 2nd Floor, Brooklyn, NY 11222
The information contained in this email message, including any attached files transmitted, is confidential and may be legally privileged. It is intended for the sole use of the individual(s) named above. If you are the intended recipient, be aware that your use of any confidential or personal information may be restricted by state and federal privacy laws. If you, the reader of this message, are not the intended recipient, you are hereby notified that you should not further disseminate, distribute or forward this email message. Email transmission cannot be guaranteed to be secured or error-free as information could be intercepted, corrupted, lost, destroyed, arrive late or incomplete, or contain viruses. The sender therefore does not accept liability for any errors or omissions in the contents of this message, which arise as a result of this e-mail transmission. If you have received this email in error, please notify the sender and immediately delete the material from your computer system. Thank you.
From: RE-wrenches <re-wrenches-bounces at lists.re-wrenches.org> On Behalf Of Rebekah Hren via RE-wrenches
Sent: Monday, February 17, 2025 1:26 PM
To: RE-wrenches <re-wrenches at lists.re-wrenches.org>
Cc: Rebekah Hren <rebekah.hren at gmail.com>
Subject: Re: [RE-wrenches] RSS: Is it necessary?
CAUTION: External Email.
I read the wrenches post regularly, as does Brian Mehalic. We have both been on CMP-4 (responsible for Article 690) for the past three code cycles. I believe a few other CMP members probably read too. The International Association of Firefighters ("largest and most influential labor unions in North America") is represented on CMP-4 and yes they do have had a lot to say about this issue.
This is definitely not the first time we have heard that certain RS devices are on balance causing more trouble than they are curing - though on the other hand some manufacturers have certainly figured out how to make safe and effective MLPE.
I'm a big fan of UL3741, I have been on that UL technical committee for about 5 years, and it is the best approach I see to expand both off-grid and grid-interactive solutions that don't require MLPE for RS. SMA for example is very present and working hard at revisions on that standard right now. At this point I can't see us having any luck in removing 690.12 requirements, except perhaps to replace the inside the array boundary voltage limit with only option as 3741 listing). So please keep asking manufacturers (inverter/rack) to pay attention to UL3741 and design products to meet the standard.
Best
Rebekah
Licensed Electrical Contractor
NABCEP Certified Solar PV Installation Professional™ 091209-85
Tel: 336.266.8800
On Mon, Feb 17, 2025 at 10:59 AM Amos Post via RE-wrenches <re-wrenches at lists.re-wrenches.org<mailto:re-wrenches at lists.re-wrenches.org>> wrote:
Seems like there has been talk of rescinding RSD requirements before on this forum. It also seems that it might gain some traction if a dedicated group of installers spoke up to the right people (Code Making Panel for instance) and put some time into it. I agree that at the very least we need reliable RSD equipment, and my preference would be less vs more.
Does anybody know if any sort of RSD is being required in Europe (not that we follow their electrical codes/ideas…just curious)???
[cid:image001.jpg at 01DB8241.C92D0EA0]
Amos Post
Integrity Energy
W 802.763.7023
C 802.291.2188
ienergyVT.com<http://www.ienergyvt.com/>
Facebook<https://www.facebook.com/integrityenergyllp?ref=hl>
On Feb 17, 2025, at 12:30 PM, david quattro via RE-wrenches <re-wrenches at lists.re-wrenches.org<mailto:re-wrenches at lists.re-wrenches.org>> wrote:
It seems anecdotal until it happens to you.
My mention of civil disobedience has been answered clearly with a “No” in this forum, and I'm fine to hear that.
I'll clarify a few points as to why I honestly think RSD has been a huge and costly mistake. I genuinely think RSD requirements should be terminated immediately. If the technology were more robust and if it worked consistently I wouldn't protest. But all the products I've tried have been trouble.
William, respectfully your analogy to seat belts is not an appropriate comparison to Rapid Shutdown. Seat-belts were required in all new cars starting in 1968 because there was statistical evidence supporting their tremendous efficacy in saving human life. Currently seat belts save about 15,000 lives per year.
Contrasting to RSD: was implemented because of the following paranoid fairytale scenario - “A firefighter is on a burning solar roof in the daytime, and wearing a metal axe at their hip. the poor guy/gal falls into live solar glass, and shatters it. The fall is so forceful that the heavy-duty fireman’s suit is punctured. Electricity conducts through the axe blade, through the suit, contacts the skin, and a DC circuit is completed through their body.”
As far as I know, this has never happened once anywhere on earth. Let’s be honest - this scenario has an incredibly low chance of ever happening in all the future of humanity. So considering that RSD has never helped anyone yet, and probably never will... How many fires can be attributed to RSD? How much property damage has occurred because of these fires?
The best path to safety for firefighters is by preventing fire disasters in the first place. Fires spread. Any fire that happens endangers property owners, tenants, business owners, neighbors, shoppers, bystanders, nearby forests, etc. RSD manufacturers aren't doing a good job right now, so we are seeing low quality unreliable electronics on the roof. I will stick my neck out and admit that installers are not always perfect. Humans make mistakes - sometimes in initial construction, and sometimes during repair and maintenance (i.e. when hunting down failed RSD's which happens far more than it should).
At this time, these devices are not being designed to withstand reality. When problems happen, manufacturers are quibbling. They ignore you until you go away, or until you sue them.
This level of "safety" is not important, and in fact RSD is causing fires every year.
On Sat, Feb 15, 2025 at 11:38 AM William Miller <william at millersolar.com<mailto:william at millersolar.com>> wrote:
David, Ray:
I have not had any problems with the Tigo RSS equipment I have installed and I have had minimal problems with optimizers and micro-inverters (which are also RSS equipment). Apparently others have had failures. We don’t know statically how serious this problem is—the posts here are purely anecdotal.
We also have not heard from the other side of the debate: the fire fighters.
Based on lack of verifiable information I can not personally conclude that RSS is all problem and no benefit.
To declare that the concept is flawed because the equipment available is not reliable is like saying we should not be required to install airbags because a bad batch of them was manufactured. We are seeing problems with the equipment needed to implement a safety requirement. That observation does not logically conclude the safety requirement is not valuable.
I hesitate to dismiss any safety requirement out of hand. Safety systems are designed to save lives and protect from injury, and most of them do. I am glad to have anti-lock brakes, smoke detectors and air bags. I have also found it quite handy to initiate RSS to allow me to work more safely on solar circuits.
Does anyone on this installers forum have contacts in the fire-response community that can comment on the their side of the issue? If RSD is really necessary for safety, then I will do my best to install good equipment properly and hold manufacturers accountable for shoddy solutions. If RSD is not that effective we need to discuss undoing the code requirements.
Sincerely,
William Miller
Miller Solar
17395 Oak Road, Atascadero, CA 93422
805-438-5600
www.millersolar.com<http://www.millersolar.com/>
CA Lic. 773985
From: RE-wrenches [mailto:re-wrenches-bounces at lists.re-wrenches.org<mailto:re-wrenches-bounces at lists.re-wrenches.org>] On Behalf Of david quattro via RE-wrenches
Sent: Saturday, February 15, 2025 6:05 AM
To: RE-wrenches
Cc: david quattro
Subject: Re: [RE-wrenches] Tigo inverter experience
RSD is the worst thing to happen to solar. Has anyone considered civil disobedience?
I wonder what would happen if all the installers banded together and refused, as a united industry ‘brotherhood.’ WE are the ones stuck with the bullshit in the aftermath.
I’m not being snarky here , this a genuine question to the group: Does anyone have good experience with RSD? i.e. you’re really glad RSD was there, and you genuinely feel safer? you’re glad and happy to comply with this code and you look forward to continuing to use RSD for the rest of your career?
On Fri, Feb 14, 2025 at 3:40 PM Ray Walters via RE-wrenches <re-wrenches at lists.re-wrenches.org<mailto:re-wrenches at lists.re-wrenches.org>> wrote:
it seems silly that we are required to install these extra pieces of equipment for added "safety", that are actually a fire hazard on the roof. Just to survey again: how many homes have been saved by RSD? How many fire fighters have actually actuated the RSD system, so that they could hack through the array to vent the roof?
I think it should only be required if you have covered so much of the roof with PV, that the fire dept can't access uncovered roof to do their venting. The whole premise of RSD is flawed. IMHO, its just another effort to block the wider adoption of solar.
When it comes to off grid, RSD causes such a decrease in reliability to amount to a decrease in safety, due to possible loss of communications, water, and heat. Add the fire hazard and RSD is really not making our customers' lives better.
Ray Walters
Remote Solar
