[RE-wrenches] How many times can a rafter have a lag screw put in and out before it is no longer structurally sound? Some roofs getting their 3rd set of new shingles

Thu May 30 12:12:03 PDT 2024

Scott,

For liability you might want a before and after inspection by a really
top inspector that you trust.

I would also ask your insurance for guidance. My insurance is always
telling me that going out of business is the typical last
straw for roofers.

Build a solar pergola😉

Dave Angelini Offgrid Solar
"we go where powerlines don't"
    [2]https://offgridsolar1.com/ [3]  [2]
e-mail  offgridsolar at sti.net
text 209 813 0060

On 2024-05-30 11:41 am, Ray Walters via RE-wrenches wrote:

> I would add to this that the size of the lag is a factor too.  3/8"
> lags into 1-1/2" wide rafters are going to cause much more damage, and
> leave larger voids, than the new 1/4" high strength lags I use now.  I
> like the rafter sistering idea, as a solution, as well as moving the
> rails up or down several inches to get away from the previous hole.  A
> third idea is staggering the mount pattern from rail to rail, which is
> something we should all be doing anyway to insure the loads are more
> equally distributed across all the rafters. Then we just change the
> pattern on the 2nd installation.
>
> Unfortunately I think much of this will be lost, since some of the
> companies that roofers subcontract with to do these remove and replace
> jobs are not always the top solar contractors.
>
> Ray Walters
> Remote Solar
>
> On 5/29/2024 10:17 PM, William Miller via RE-wrenches wrote:
>
>> Scot:
>>
>> Fascinating question.  It's a bit ironic that the changing climate is
>> damaging the equipment we are utilizing to combat climate change.
>>
>> A lag unscrewed will damage a wooden member less than a lag ripped
>> out.  From your post it seems we are dealing with the former, rather
>> than the latter.
>>
>> If your layout isn't changing there is a likelihood that the new
>> mounting locations will be at our near the old mounting locations.
>> This will be true for a rafter lag or deck mount screw.  It seems to
>> me the process of re-screwing in the same spot in a rafter is just as
>> questionable as re-screwing in the same spot in sheeting.  I see no
>> benefit in deck mounting and many disadvantages.
>>
>> If severe weather is an issue I would avoid deck mounting unless you
>> have vetted the decking and the applicability of the chosen fasteners
>> to that material.  I would not standing-seam mount without knowing how
>> the sheeting panels are secured and finding a method to calculate how
>> many clips are needed given the increasing wind loads.
>>
>> I see two questions about reinstalling screws repeatedly:
>>
>> 1.   Is the rafter less able to support loads?  Or,
>>
>> 2.   Is the rafter (or decking) less able to retain the fasteners
>> holding the PV to the roof?
>>
>> Speculation on the above:
>>
>> 1.   Wood fibers adhere to each other.  They are not like a bundle of
>> straws.  If you damage a fiber in one place, it is supported on either
>> side of the point of damage by this adherence.  My guess is by just
>> withdrawing screws a few times you do not compromise the load handling
>> ability of a rafter member.  Site built rafters require different
>> considerations than trusses.  Site built are a wild-card and need to
>> be considered on a case-by-case basis.
>>
>> 2.   If you penetrate wood with screws multiple times in a small area,
>> you are going to make that area "soft."  Screw holding capabilities
>> will be drastically reduced.
>>
>> Options that I see:
>>
>> 1.   Flashed stanchions.  The lags never need to be removed.
>>
>> 2.   Blocking, to attach in new locations.
>>
>> 3.   Sistering, again to attach in new locations.
>>
>> 4.   Not deck mounting (IMHO).
>>
>> Anecdote:  We had a tile roof mount inspected one August afternoon.
>> The inspector insisted on looking in the attic.  We asked why and he
>> said this city has a particular concern about structural integrity of
>> wood framed roofs.  I was aware of this because I have had some silly
>> arguments about this with the lead inspector.  Apparently they have
>> seen a lot of big-box solar company installers drive lags carelessly
>> and had the lags blow out the side of the rafter.  If they spot this
>> they make the installer hire an engineer and design a system to sister
>> the rafters to engineering standards.  I totally get this concern.  We
>> use a rafter locator and are really careful.  This is not to say we
>> have not had a blow out now and then.  You gotta have a feel for the
>> torque resistance of a lag while seating.
>>
>> Thank you for bringing this up.  As I said, fascinating (to this
>> wonk).
>>
>> William
>>
>> Miller Solar
>>
>> 17395 Oak Road, Atascadero, CA 93422
>>
>> 805-438-5600
>>
>> www.millersolar.com [1]
>>
>> CA Lic. 773985
>>
>> From: RE-wrenches [mailto:re-wrenches-bounces at lists.re-wrenches.org]
>> On Behalf Of Scot Arey via RE-wrenches
>> Sent: Wednesday, May 29, 2024 3:16 PM
>> To: 'RE-wrenches'
>> Cc: scot.arey at solarcentex.com
>> Subject: [RE-wrenches] How many times can a rafter have a lag screw
>> put in and out before it is no longer structurally sound? Some roofs
>> getting their 3rd set of new shingles
>>
>> With all our Texas hail storms, we now have roof solar systems that
>> might have to come down for the third time as hail-pockmarked shingles
>> need replacement. We're at the 11-year mark of doing business and we
>> have some customers ready for another insurance roof claim,
>>
>> So that means a new set of lag screws drilled into rafters...after how
>> many times is that 2x6 rafter not 2x6 strength?
>>
>> I've asked this to my 3rd party structural engineer and instead of an
>> answer got a "wow, hadn't thought of that." We've considered going to
>> deck mounts to avoid rafters at the 3rd "detach and reset."
>>
>> Any of you guys consider this and have your techniques? I suppose in
>> perfect world, the mount would stay in place and roofer would shingle
>> around it but we still use old-school metal flashing so that is really
>> not possible. I look forward to hearing your thoughts on this.
>>
