[RE-wrenches] BTS

[frenergy]

Wrenches,

        Thanks for all the response regarding the OB BTS.  Fortunately I have since found an old OB version banging around so will head back to the install to swap it out.

Bill


  ----- Original Message -----
  From: boB at midnitesolar.com
  To: RE-wrenches
  Sent: Friday, September 12, 2014 6:51 PM
  Subject: Re: [RE-wrenches] BTS


  On 9/12/2014 6:40 PM, All Solar, Inc. wrote:

    Pretty sure Midnite sent out some of the classics with a Magnum BTS. Due to part shortage.?
    Installed one in June this year.



  Yep.   Gotta stay on top of this stuff, especially when building in the good ole US of A !

  Luckily, it was a short lived issue.  But, different  and kinda fun in a way.

  boB





    Jeremy Rodriguez,
    President



    All Solar, Inc.
    1463 M

    Penrose Colorado 81240
    719-372-3808 office
    719-372-3804 fax
    www.asolarelectric.com


    Sent by Jeremy's iPhone. Sorry for typos and shorthand!

    On Sep 12, 2014, at 4:10 PM, "boB at midnitesolar.com" <boB at midnitesolar.com> wrote:



      2 cents here...

      As far as I remember,  OB is 10K Ohms (at 25degrees C), MidNite is 10K,
      Magnum is 100K and Xantrex/Trace/Schneider is 100K

      Magnum has a couple of swapped lines compared to the other BTS' but ~may~ or may not
      work for others in some instances.

      boB


      On 9/12/2014 2:48 PM, Jerry Shafer wrote:

        No it will not work right

        On Sep 12, 2014 2:56 AM, "frenergy" <frenergy at psln.com> wrote:

          Wrenches,

                  I just replaced a failed XW..... is the XW BTS compatible with an FM60?  Thanks in advance,

          Bill

          <mime-attachment.jpg>
